Transparent bi-directional converter of MODBUS TCP protocol to MODBUS RTU or ASCII protocol via Ethernet operation, capable of communicating with meters via RS485.
Transparent bi-directional converter of MODBUS TCP protocol to MODBUS RTU or ASCII protocol via Ethernet operation
Transparent Data Transmission
Upgrade Files via Web Server
Modbus-TCP Protocol
Modbus-RTU Protocol
Bi-Directional Protocol Conversion
Local Configuration & Maintenance
Support WiFI AP Mode
Telnet Access Module
Parameter Configuration
TCP Client Mode
Server Mode
Ethernet, DHCP, Fixed IP
Status View
Ethernet, DHCP, Fixed IP
Parameter Configuration
Technical Data
Operation Temperature | -25°C to +75°C |
Humidity Range | 20% RH to 90% RH, No Condensation |
Operation Voltage | 5 - 36 DVC |
Consumption | 12 V, <80 mA |
Baud Rate | 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 384000, 921600 |
Local Configuration | WiFi / Ethernet |
Dimension | 90 mm (L) x 17.5 mm (W) x 62 mm (D) |
Installation | DIN Rail Mounting |
Communication Method | RS485, RJ45, WiFi AP Communication |
| |
| Power Indicator, power supply: green light on otherwise green light off |
| Communication indicator, lighted when data is transmitted |
| LED0, always on at 10 MBp/s connection, blinks during data transfer |
| LED1, always on at 100 MBp/s connection, blinks during data transfer |
