Half Duplex Communication (uplink 8 channels, downlink 1 channel)
Working Frequency: 433 MHz @ LoRa & 900 / 1800 / 2100 MHz @ 4G
Access Mode Support: Ethernet (10/100 Base-T) / WiFi / 4G
Transmission Distance: 5KM (line of sight)
Support Remote Configuration, Status Query, Log & Alarm Management, Firmware Upgrades
Support Manual Mapping Relationship
Support up to 8 LoRa™ Nodes concurrently
Support 2.4GHz Data Backhaul
Support RS485 Local Communication
Support VPN (Virtual Private Network)
Able to set APN (Access Point Name)
Support Virtual Private Network
Efficient Power Consumption
Integrated LoRa™ Technology
Stable Data Transmission
Robust Range
8 LoRa™ Nodes Concurrently
Access Point Name Configuration
Half Duplex Communication
Log & Alarm Management
LED Indicator Status
LoraWAN™ Protocol
Remote Configuration
Local Configuration
Data Backhaul
Support Secure Encryption
Technical Data
Operation Temperature | -40°C to +75°C |
Humidity Range | 10% RH to 90% RH, No Condensation |
Operation Voltage | DC 9 V - 48 V |
Current | < 5 W |
Antenna | SMA (female) connector can be connected short or long type antenna |
LoRa™ Parameters |
|
| |
| Gateway Is Powered On |
| Loader Starting |
| Application Working Normally |
| Network Status Is Abnormal |
| Network Status Is Normal |
| Communication |
| LoRa™ Status Is Abnormal |
| LoRa™ Status Is Normal |
| Communication |
LEGAL DIRECTIVE / STANDARD
EN301511
EN62311
EN301 489-1/52
EN301 908-1/2/13
EN62368
EN60529
