Support LoRa™ for uplink, frequency: 433MHz
Support RS232 with CTS / RTS for downlink communication with meter.
Support USB port for locally configuration
Flexible LoRa™ Tx power level setting (5 ~ 20dBm)
Equips one USB port to configure the module.
Provide backup power (super capacitor) for LoRa module in case of no external power from meter.
The LoRa Module can be working as universal module, it means can be integrated with all brand meter of TNB’s suppliers (EDMI, Itron, MiM & Krizik)
Supports long distance communication, so that can easily access the meter in the steel meter box or in the basement. (Indoor Range: 2 KM, Outdoor Range: 11.5 KM)
Universal Module
Efficient Power Consumption
Integrated LoRa™ Technology
Stable Data Transmission
Robust Range
High Sensitivity
Transparent Transmission
Equipped With Super Capacitor
Multiple Baud Rates
LED Indicator Status
LoraWAN™ Protocol
Remote Upgrades (FOTA)
Local Configuration
Anti-Interference Capability
Highly Reliable Performance
Technical Data
Operation Temperature | -40°C to +85°C |
Humidity Range | 10% RH to 90% RH, No Condensation |
Operation Voltage | DC 9 V - 14.5 V |
Current | < 500 mW |
Antenna | SMA (female) connector can be connected short or long type antenna |
LoRa™ Parameters |
|
| |
| Power On |
| Power Off / Cannot Power On Normally |
| Modem Sending Data to ME |
| Modem Receiving Data from ME |
| Modem Receiving Data from ME |
LEGAL DIRECTIVE / STANDARD
EN300220
EN301 489-1
EN301 908-52
EN62368
EN62311
EN60529
